- 56 -
4.7.1 MAC Address Filter
ress Filter of Web Smart PoE Switch.
This section introduces detail information of MAC Address Filter of Web Smart PoE Switch; the screen in Figure 4-49
appears and table 4-22 & 4-23 descriptions the MAC Add
Figure 4-49 MAC Address Filter Web Page Screen
Table 4-22 Descriptions of the MAC Address Filter Screen Objects
Table 4-23 Descriptions of the MAC Address Filter Screen Objects
Object Description
MAC Address
Allow to input three MAC Address on per port of Web Smart PoE Switch.
Select Port
Allow to select port 1 to port 16 (FNSW-1608PS), port 1 to port 18 (FGSW-1828PS).
Binding
Allow to itch. Disable or Enable the binding function on each port of Web Smart PoE Sw
Apply
Press this button for save current configuration of Web Smart PoE Switch.
Object Description
Port
Indicate port 1 to port 16 (FNSW-1608PS), port 1 to port 18 (FGSW-1828PS).
Binding Status
Display Binding Status from each port of Web Smart PoE Switch.
MAC 1
Display first assigns MAC Address on each port of Web Smart PoE Switch.
MAC 2
Display second assigns MAC Address on each port of Web Smart PoE Switch.
MAC 3
Display third assigns MAC Address on each port of Web Smart PoE Switch.
