- 52 -
4.6.2 Class of Service Configuration
on of Web Smart PoE Switch.
This section introduces detail information of Class of Service Configuration of Web Smart PoE Switch; the screen in Figure
4-45 appears and table 4-19 descriptions the Class of Service Configurati
Figure 4-45 Class of Service Configuration Web Page Screen
Table 4-19 Descriptions of the Class of Service Configuration Screen Objects
Object Description
Enable High Priority
enable the High Priority function. Default mode is Enable. Allow to disable or
Port
Indicate port 1 to port 16 (FNSW-1608PS), port 1 to port 18 (FGSW-1828PS).
Port Base
y based on Port Base policy. Define per port Class of Service polic
VLAN Tag
Define per port Class of Service policy based on VLAN Tag priority policy.
IP /DS
Define per port Class of Service policy based on IP / DS policy.
Apply
Press this button for save current configuration of Web Smart PoE Switch.
