- 46 -
Table 4-14 Descriptions of the Port Based VLAN Configuration Screen Objects
Port Based VLAN Setting example:
VLAN scenario
1. Port 18 is the file server port for all the workstations
2. Port 1 to port 17 is different devices that do not need to see each other
Setup steps
1. Port Setting
1.1 Assign VLAN 1 for the first VLAN group with port 1 and port 18.
1.2 Assign VLAN 2 for the second VLAN group with port 2 and port 18
1.3 Repeat the same steps for port 3 to port 18. i.e. 3 & 18, 4 & 18….., 17 & 18
After the above steps port 1 to port N groups (different
LAN). However, they all can access port 18 due to port 18 is using overlapping feature to communicate with port 1 to port
17
.
17 is being separated physically due to it belongs to different VLA
V
Object Description
VID
Display different VLAN ID from multi-port based VLAN groups.
VLAN Name
Assign and display different VLAN name from multi-port based VLAN groups. Up to maximum 8
characters allow.
Port
Indicate port 1 to port 16 (FNSW-1608PS), port 1 to port 18 (FGSW-1828PS).
Member
Allow to click specific port as member port from different port based VLAN groups.
Apply button
Press this button for save current configuration of Web Smart PoE Switch.
Delete Group
Press this button for delete existence port based VLAN groups.
Add New Group
Press this button for create a new port based VLAN groups.
