Planet G.SHDSL Bridge/Router GRT-402 User Manual

PLANET Technology Corp. GRT-101/401/402 User’s Manual
Web UI Configuration
After connection via web browser, click BRIDGE and CPE Side to setup
Bridging mode of GRT series and then click Next for the next setting.
1. Enter WAN1 VPI: 0 and VCI: 32.
2. Select WAN1 AAL5 Encap: LLC
3. Enter LAN IP: 192.168.0.1
4. Enter LAN Sub-net Mask: 255.255.255.0
5. Enter Gateway: 192.168.0.254
The Gateway is directly pointed to the BAS IP.
6. Click Next
7. The screen will prompt the new configured parameters. Check the
parameters and click Restart, the router will reboot with the new setting or
click Continue to configure other parameters.
- -
11

Planet G.SHDSL Bridge/Router GRT-402 Specifications

General

Brand	Planet
Model	G.SHDSL Bridge/Router GRT-402
Category	Network Router
Language	English
