PLANET Technology Corp. GRT-101/401/402 User’s Manual
Hardware Specification
WAN/LAN Ports RJ-11 SHDSL WAN port x1
10/100Mbps LAN port x1 on GRT-101
10/100Mbps LAN port x4 on GRT-401/GRT-402
Connector RJ-11 connector for WAN, RJ-45 connector for LAN
Cabling
Requirement
G.SHDSL : AWG26 or higher
10 /100 Base T: UTP/STP Category 3 or 5
LEDs SHDSL, Power Status, WAN Link and Action Status, LAN
Link/Active (and 100M Status), Alram
Speed SHDSL: 64Kbps to 2.304Mbps or
128Kbps to 4.608Mbps (for GRT-402, 4-wire
mode)
LAN Switch: 10/100 Mbps
Power External power adapter 9V DC, 1000mA
Environmental Operating temperature: 0° to 45°C
Storage temperature: -10° to 70°C
Housing Plastic Case
Dimension 145 mm x 187 mm x 33 mm (L x W x H)
- -
3
