Planet GS-5220-16S8C Command Guide

Command Guide
-257-
<Instance> The MEP instance number.
voe MEP is VOE based
Default:
0
Usage Guide:
To set VOE of MEP.
Example:
To set VOE (8) of MEP 1
Switch# configure terminal
Switch (config)# mep 1 voe
4.2.147 monitor destination
Command:
monitor destination interface 10GigabitEthernet <port_type_list> | GigabitEthernet
<port_type_list>
monitor Set monitor configuration
destination The destination port. That is the port that trafficked should be mirrored to
Default:
Disabled
Usage Guide:
To configure Mirroring Port
Example:
To set Mirroring Port (GigabitEthernet 1/2)
Switch# configure terminal
Switch (config)# monitor destination interface GigabitEthernet 1/2
4.2.148 monitor source
Command:
monitor source interface * | 10GigabitEthernet <port_type_list> | GigabitEthernet
<port_type_list> { both | rx | tx }
monitor Set monitor configuration
