User’s Manual of IMG-110T
-17-
3.2 Requirements
■ Ethernet Port Connection
• Workstations running Windows XP/2003/Vista/7/8/2008/10, MAC OS X or later, Linux, UNIX, or other platforms are
compatible with TCP/IP protocols.
• Workstations are installed with Ethernet NIC (Network Interface Card)
Network cables -- Use standard network (UTP) cables with RJ45 connectors.
The above PC is installed with Web browser and JAVA runtime environment plug-in.
It is recommended to use Internet Explorer 8.0 or above to access the Industrial Modbus
Gateway. If the Web interface of the Industrial Modbus Gateway is not accessible, please
turn off the anti-virus software or firewall and then try it again.
3.3 Management Methods
The way to manage the Industrial Modbus Gateway:
- Web Management interface
- Remote IP-based Telnet interface
3.3.1 Web Management Interface
The Industrial Modbus Gateway offers management features that allow users to manage the Industrial Modbus Gateway from
anywhere on the network through a standard browser such as Microsoft Internet Explorer. After you set up your IP address for
the Industrial Modbus Gateway, you can access the Industrial Modbus Gateway’s Web interface applications directly in your
Web browser by entering the IP address of the Industrial Modbus Gateway.
Figure 3-3: Web Management Diagram
You can then use your Web browser to list and manage the Industrial Modbus Gateway configuration parameters from one
central location. Web Management requires either Microsoft Internet Explorer 8.0 or later, Google Chrome, Safari or
Mozilla Firefox 1.5 or later.
