User’s Manual of IMG-110T
-9-
1.5 Product Features
Serial Interface
■ One RS422/485 port with 5-contact terminal block
■ Cost effective for RS422/RS485 to Fast Ethernet 10/100BASE-TX application
■ Supports 4-wire RS422 or 2-wire RS485 with 5-contact terminal block operation
■ 300bps~115200bps baud rate and non-blocking communication
Ethernet Interface
■ Complies with IEEE 802.3, IEEE 802.3u 10/100BASE-TX standard
■ Supports 10/100BASE-TX RJ45 port with distance up to 100m
Serial Operation Modes
■ Software Protocol supports Modbus TCP, Modbus RTU, Modbus ASCII, IP, ARP, DHCP and DNS
■ Supports RTU Master, RTU Slave, ASCII Master, and ASCII Slave four serial operation modes via management
interface
■ Master mode supports 32 slave TCP connection requests
■ Slave mode supports 16 TCP master connections
Management Function
■ Built-in IP-based Web interface and telnet interface for remote management
■ Supports IP address and MAC address filtering function
■ PLANET Modbus Gateway utility for finding client device on the network and related IP subnet address setting to
reset to factory default function
■ PLANET Smart Discovery utility automatically finds the client devices on the network
■ Firmware upgrade/configuration backup and restore via HTTP protocol
Hardware
■ LED indicators for system, network and RS422/585 port diagnostics
■ DIP switch on the upper panel for resetting to factory default
■ Wall-mount kit
Industrial Case and Installation
■ Wall mount-type IP40 metal case
■ The 2-contact terminal block connector on the top panel of Industrial Modbus Gateway is used for DC power input
(9-48V)
■ -40 to 75 degrees C operating temperature
