Planet IMG-110T User Manual

User’s Manual of IMG-110T
-10-
1.6 Product Specifications
Model IMG-110T
Serial Port
Interface
RS422/ RS485 x 1
Connector
5-contact terminal block for RS422/RS485
Surge Protection 1KV
Baud Rate (Data Rate)
300bps to 115200bps
Data Bits
7, 8
Parity Type
Odd, Even, None, Space, Mark
Stop Bit
1, 2
Flow Control
H/W, None
Signals
RS422 : Tx+, Tx-, GND, Rx+, Rx-
RS485: Data A (+), GND, Data B (-)
Distance
RS422/RS485 for 20m transfer distance
Operation Mode
RTU Master/RTU Slave/ASCII Master/ASCII Slave
Master mode: Supports up to 32 slave TCP connection requests
Slave mode: Supports up to 16 TCP master connection requests
Ethernet Port
Standard
IEEE 802.310BASE-T standard
IEEE 802.3u 100BASE-TX standard
IEEE 802.3x full-duplex flow control
Connector
RJ45
Distance
100 meters
Hardware
Copper Port
10/100BASE-T RJ45 TP x1, auto-MDI/MDI-X, auto-negotiation
Serial Port
RS422/RS485 x 1
DIP Switch
Reset system to factory default
LED Indicators
System: Power x 1
10/100BASE-TX Port: Link/Active x 1
RS422/RS485 Serial Port: TX (Transmit) x 1, RX (Receive) x 1
Dimensions (W x D x H)
69 x 100 x 22 mm
Weight
238g
Power Input Connector
2-contact terminal block connector DC power (9-48V) *
Power Consumption
1.1 watts / 3.7BTU (max.)

Planet IMG-110T Specifications

General

Brand	Planet
Model	IMG-110T
Category	Gateway
Language	English
