User’s Manual of IMG-110T
-48-
• Parity Bits
It is a simple method to check out fault in serial communication; it has 4 types:
Even/Odd/Mark/Space.
• Flow Control
Flow control is determined by product hardware. For some reason, it cannot
communicate. When communication is blocked, open the flow control to ease. Flow
control allows the data receiving device to notify the data sending device when it is
unable to receive the data, so that it can be stopped. It includes XON/XOFF,DTR/DSR,
and RTS/CTS.
• Work Mode
Work mode is determined by product hardware. When the product is RS485 serial port,
it will display RS-485. When the product is the RS232 interface, it will display RS-232.
• Advance Settings
According t
o the needs, the user can modify the output state of the DTR and RTS
signals at any time
• RTS Ctrl
RTS signal is automatically set to the ON state after every time you open the serial port,
and it is forbidden to change the user to modify. (When the RTS flow control mode is
turned on, it is invalid.)
[Force OFF]
RTS signal is automatically set to the OFF state after every time you open the serial
port, and it is forbidden to change the user to modify. (When the RTS flow control mode
is turned on, it is invalid.)
• DTR Ctrl
DTR signal is automatically set to the ON state after every time you open the serial port,
and it is forbidden to change the user to modify. (When the DTR flow control mode is
turned on, it is invalid.)
[Force OFF]
DTR signal is automatically set to the OFF state after every time you open the serial
port, and it is forbidden to change the user to modify. (When the DTR flow control mode
is turned on, it is invalid.)
• Apply to All Ports
Choose this option to apply the setting to all ports.
Button
: Click to apply changes.
