User Manual of WNAP-W2200
-5-
1.4 Product Specifications
Product
WNAP-W2200
300Mbps 802.11n Wireless In-wall Access Point
Hardware Specifications
PoE Port
1 x 10/100Mbps Auto MDI/MDI-X RJ45 port (Rear Panel)
※ IEEE 802.3af PD Port
LAN Port 1 x 10/100Mbps Auto MDI/MDI-X RJ45 port
RJ-11 Port Connect to the telephone through the 4-conductor phone line
4-pin Terminal Block
Connect to the PBX through the 4-conductor telephone wire
(Rear Panel)
Interface
USB Port USB 2.0, Type-A, 5V DC/0.5A Output
PoE IEEE 802.3af
Antenna Built-in 3dBi antenna x2
Reset Button
Reset button on front panel
Press over 7 seconds to reset the device to factory default
LED Indicators PWR/SYS LED
Material Plastic
Dimensions (W x D x H) 86 x 86 x 35 mm (L x W x H)
Weight 103g
Power Requirements 48V DC, 320mA
Power Consumption < 10W
Wireless interface Specifications
Standard Compliant with IEEE 802.11b/g/n
Frequency Band
America/ FCC: 2.414~2.462GHz (11 Channels)
Europe / ETSI: 2.412~2.472GHz (13 Channels)
Channel Width 20 or 20/40MHz
Transmission Distance
Indoor up to 100m
Outdoor up to 300m (it is limited to the environment)
RF Power
(Intentional Radiator)
IEEE 802.11b: 18dBm
IEEE 802.11g: 15dBm
IEEE 802.11n: 15dBm
Wireless Management Features
Wireless Modes Access Point (Dual-SSID)
Encryption Security
WEP (64/128-bit)
WPA-PSK (TKIP) / WPA2-PSK (AES)
WPA (TKIP) / WPA2 (AES)
802.1x Authentication
Enable/Disable SSID Broadcast
Wireless Security
Wireless LAN ACL (Access Control List) MAC filtering
AP Isolation: Enable it to isolate each connected wireless client
Wireless Advanced
Supports 802.11e WMM (Wi-Fi Multimedia), 802.1Q VLAN
Max. Supported Clients Wired: Not limited
