Chapter 2. Hardware Installation
Please follow the instructions below to connect the WNAP-W2200 to the existing network devices and your computers.
2.1 Product Outlook
 Dimensions: 86 x 86 x 35 mm (L x W x H)
 Diagram :
Front View Rear View
Side View Bottom View
Figure 2-1 WNAP-W2200 Product Outlook
