Note
It is recommended to use PLANET SFP+s on the
Media Converter. If you insert an SFP+ transceiver
that is not supported, the Media Converter will not
recognize it.
10GBASE-X SR/LR:
Before connecting the other switches, workstation or Media
Converter, please do the following:
1. Make sure both sides of the SFP+ transceiver are with the
same media type; for example, 10GBASE-SR to 10GBASE-SR,
10GBASE-LR to 10GBASE-LR.
2. Check whether the ber-optic cable type matches the SFP+
transceiver model.
 To connect to 10GBASE-SR SFP+ transceiver, use the
multi-mode ber cable with one side being the male
duplex LC connector type.
 To connect to 10GBASE-LR SFP+ transceiver, use the
single-mode ber cable with one side being the male
duplex LC connector type.
Connecting the ber cable
1. Attach the duplex LC connector of the network cable to the
SFP+ transceiver.
2. Connect the other end of the cable to a device like a switch
with SFP+ installed, ber NIC on a workstation or a Media
Converter.
 Removing the Transceiver Module
1. Make sure there is no network activity by consulting or
checking with the network administrator. Or through the
management interface of the switch/converter (if available),

Planet XT-705A Specifications

General

Jumbo frames	16000
Duplex system	Full, Half
Auto MDI/MDI-X	Yes
Networking standards	IEEE 802.3ab, IEEE 802.3ae, IEEE 802.3an, IEEE 802.3bz, IEEE 802.3u, IEEE 802.3x
Cable types supported	Cat5, Cat5e, Cat6, Cat6a, Cat7
Ethernet interface type	2.5 Gigabit Ethernet, 5 Gigabit Ethernet, 10 Gigabit Ethernet, Fast Ethernet, Gigabit Ethernet
Maximum data transfer rate	10000 Mbit/s
Fiber ethernet cabling technology	10GBASE-X
Fiber optic connector	SFP+
Connectivity technology	Wired
Ethernet LAN (RJ-45) ports	1
Internal	No
Certification	FCC Part 15 Class A, CE
LED indicators	Link, Power
Housing material	Metal
Input current	2 A
Input voltage	5 V
Power consumption (typical)	26 W
Wavelength	- nm
Fiber mode structure	Multi-mode, Single-mode
Maximum transfer distance	60000 m
Fiber cable diameters supported (core/cladding)	9/125, 50/125, 62.5/125 µm
Storage temperature (T-T)	-10 - 70 °C
Operating temperature (T-T)	0 - 50 °C
Operating relative humidity (H-H)	5 - 95 %
Harmonized System (HS) code	85176990

Weight and Dimensions

Depth	70 mm
Width	94 mm
Height	26 mm
Weight	180 g
