6 UNPACKING THE X-RAY UNIT
16
Planmeca ProOne
Installation Manual
NOTE
Attach
felt pads
(included
in the
delivery)
to
the underside
of
the
column base
plate
before
you lift up the X-ray unit.
3.
Lift u
p the X-ray
unit and the
support fra
me (6).
NOTE
Never lift the X-ray unit
from the patient hand
les.
4.
Remove the two transport locking p
ins from the back of the X-
ray unit.
ProO_Pack
3
.eps
6
17
19
