7 INSTALLING THE X-RAY UNIT
Installation Manual Planmeca ProOne 17
7 INSTALLING THE X-RAY UNIT
The X-ray unit must be installed in a location where the user can freely monitor the patient
during the whole imaging process. For minimum operational space requirements, see
section 3.8 "Space requirements" on page 8.
7.1 Attaching the X-ray unit to the wall
The wall bracket installation must be able to resist a pull-out force of 2759 N (276 kg, 608
lb).
For dimensions of the wall bracket and the optional extension plate, see section 3.9
"Dimensions for wall bracket and optional extension plate" on page 11. For installation
drawing, see section 11 "DIAGRAMS" on page 37.
