Installation Manual Planmeca ProOne 11
3.9 Dimensions for wall bracket and optional extension plate
Figure 1: Wall bracket
Figure 2:
Extension plate for wall bracket (optional)
A
(B)
C
D
E
50 mm (2 in.)
180 mm
(7.1 in.)
150 mm
(5.9 in.)
wallbracket_dim.eps
A
(B)
C
D
E
240 mm
(9.45 in.)
50 mm (2 in.)
25 mm (1 in.)
406.4 mm
(16 in.)
10 mm
(0.4 in.)
