3 PRE-INSTALLATION REQUIREMENTS
Installation Manual Planmeca ProOne 5
FOR X-RAY UNITS WITH DETACHABLE POWER SUPPLY CORD
The X-ray unit can be disconnected from the mains power supply by unplugging the power
cable.
Never place or hang any objects on any part of the X-ray unit.
Make sure that you cannot get caught or hooked up on any part of the X-ray unit. Keep
loose items of clothing, hair and jewellery tucked away safely.
3.2 Environmental requirements
Transport
• Temperature -20°C - +60°C (-4°F - +140°F)
• Relative humidity 10 - 90% RH (non-condensing)
• Air pressure 700 - 1060 hPa
Storage
• Temperature -10°C - +50°C (+14°F - +122°F)
• Relative humidity 10 - 90% RH (non-condensing)
• Air pressure 700 - 1060 hPa
Operating
• Temperature +10°C - +40°C (+50°F - +104°F)
• Relative humidity 10 - 90% RH (non-condensing)
• Air pressure 800 - 1060 hPa
• Max. altitude 2000 m (1.25 miles)
If the X-ray unit has been stored at temperatures below +10°C (+50°F) for more than a few
hours, time must be allowed for the unit to reach room temperature before connecting it to
the mains voltage.
3.3 Radiation protection
The room in which the X-ray unit is to be installed and the position from where the user is
to operate the equipment must be correctly shielded from radiation. Since radiation safety
requirements vary from country to country and state to state it is the responsibility of the
installer to ensure that all safety regulations are met.
FAILURE TO INSTALL THE X-RAY UNIT IN AN APPROVED LOCATION MAY BE
DANGEROUS TO BOTH PATIENT AND OPERATOR.
Protect yourself from radiation when you check the radiation beam alignment.
