Planmeca ProOne - Panoramic Exposure Procedures; Procedure for Full Size Panoramic Exposure

Planmeca ProOne
Remote Button US
06.03.2017 LY
USB Memory Ethernet
Exposure Switch
Remote Exposure Option
1 --> 1
2 --> 2
5 --> 5
6 --> 6
Ethernet cable UTP cat5e
06320060
Exposure Extension
Cable 10005679
PC with grabber card
Exposure Spiral
Cable 10001193
Data wall socket
assembly 06001019
Exposure switch
10029350
Exposure Spiral
Cable 10001193
NOTE
Cross connected Cable
USB
Rem
EXP
Opt.
EXP
Switch Ethernet
Cable MHS 1x5x0.5 Code 06320032
Exposure Extension
Cable 10005679
1
3
5
6
4
2
US Wall Termination
Units 10008847
1
3
5
6
4
2
Exposure
Spiral Cable
Exposure switch
1
16
6
Modular Jack
RJ-12
EXP
+26V
Ready Lamp
EXP Lamp
1
3
5
6
4
2
Exp osur e sw it ch
10029350
