TECHNICAL SPECIFICATIONS
50 Planmeca ProX
User’s Manual
Mechanical data
Environmental requirements
External mains fuse recommendation
The recommendation for the external mains fuses are:
• units with 100V~ or 115V~ voltage setting: 16A, time lag
• units with 220-240V~ voltage setting: 10A, time lag
No other equipment should be connected to the same fused mains line as the x-ray unit. In some
countries an additional external fault current guard is also required.
Original manufacturer
PLANMECA Oy,
Asentajankatu 6,
FIN-00880, Helsinki,
FINLAND
Phone: +358-20-7795 500
Fusing units with 100V~ or 110-115V~ voltage
setting: 15AT, 250V, slow blow (6.3x32mm)
(special fuse, manufacturer Bussmann,
type MDA)
units with 220-240V~ voltage setting:
8AT, 250V, slow blow (6.3x32mm)
(special fuse, manufacturer Bussmann, type MDA)
Duty cycle 1:12, automatic control, at least 6 seconds
Electrical classification Class I Type B
Weight total 29 kg (64 lbs)
tube head
4.2 kg (9.3 lbs) with standard cone
4.5 kg (10 lbs) with long cone
Color RAL 9016
Ambient temperature operating +5°C - +40°C
storage -10°C - +50°C
transport
-10°C - +50°C
Humidity 25% - 75%
Atmospheric pressure range 700 hPa - 1060 hPa
