Planmeca ProX 55
TECHNICAL SPECIFICATIONS
User’s Manual
22.5 User’s statement for Planmeca Prox
Radiation leakage technique factors
The maximum rated peak tube potential is 70 kV and the maximum rated continuous tube current is
0.14 mA for the maximum rated peak tube potential.
Minimum filtration
The radiation port contains an added 1.5 mm aluminium filtration. The measured half-value is 0.50 -
0.55 at 70 kV. The measured value corresponds to an aluminium equivalent of 2.5 mm.
Rated line voltage
100, 110-117, 220-240 V~ ±10%. Line voltage regulation 10%.
Maximum line current
5A at 230V, 7,4A at 115V
Technique factors that constitute the maximum line current condition
70 kV, 6 mA
Generator rating and duty cycle
1.4 kW, duty cycle 1:30. The wait period is controlled automatically by calculating it according to the
formula tw = 30 x texp.
Maximum deviation of peak tube potential from indicated value
± 2.0 kV
Maximum deviation of tube current from indicated value
± (5% + 0.2 mA)
Maximum deviation of exposure time from indicated value
± (5% + 0.001 sec)
