2 Planmeca ProX

User’s Manual

2 SYMBOLS

Type B equipment (Standard IEC 601-1).

Alternating current (Standard IEC-417).

Attention, consult accompanying documents

(Standard IEC 601-1).

General warning (Standard ISO 7010).

Warning, electricity (Standard ISO 7010-W012).

Intermediate focal spot (Standard IEC-417).

Separate collection for electrical and electronic equipment

according to Directive 2002/96/EC (WEEE).

Default Chapter3
- Table of Contents3
1 Introduction5
2 Symbols6
3 Associated Documentation7
4 Safety Precautions8
- Explanations for Note, Caution and Warnings Statements8
- Notes, Cautions and Warnings8
5 Checklist - before Using the Unit10
6 Planmeca Prox Intraoral X-Ray Unit - Main Parts11
- General View of the X-Ray11
- Control Panel11
7 Preparations for the Exposure12
- Switching the Unit on12
- Selecting the Cone13
8 Control Panel16
- Displays16
- Keys and Indicator Lights18
9 Molar Exposure21
- Selecting the Exposure Parameters21
- Patient Positioning22
- Taking an Exposure24
10 Premolar and Canine Exposure25
- Selecting the Exposure Parameters25
- Patient Positioning26
- Taking an Exposure27
11 Incisor Exposure28
- Selecting the Exposure Parameters28
- Patient Positioning29
- Taking an Exposure30
12 Occlusal Exposure31
- Selecting the Exposure Parameters31
- Patient Positioning32
- Taking an Exposure33
13 Endodontic Exposure34
14 Bite-Wing Exposure35
- Selecting the Exposure Parameters35
- Patient Positioning36
- Taking an Exposure37
15 Exposure Values38
- Default Exposure Values38
- Preprogrammed Settings Values38
16 Programming Exposure Values40
- Programming Default Exposure Values40
- Programming the Density Values41
- Programming the Preprogrammed Settings42
17 Exposure Value Tables44
- Exposure Values for Planmeca Prosensor and Planmeca Dixi2 V3 Sensors44
- Exposure Values for Dixi2 V1 Sensors (High Sensitivity)46
- Exposure Values for Speed F Films48
18 Error Codes50
19 Cleaning51
- Surfaces51
- Film Holder51
20 Service51
21 Disposal of the Unit52
22 Technical Specifications53
- Technical Data53
- Dimensions (in MM)55
- Planmeca Prox Minimum Dimensions56
- Installation Options58
- User's Statement for Planmeca Prox59

Type	Intraoral X-ray
Tube current	7 mA
Imaging Technology	Digital
Focal spot	0.4 mm
X-ray generator	High-frequency
Power Requirements	100–240 V AC, 50/60 Hz
Tube voltage	60-70 kV
