CONTROL PANEL
14 Planmeca ProX
User’s Manual
8.2 Keys and indicator lights
8.2.1 Preprogrammed setting keys and indicator lights
The unit is preprogrammed with exposure parameters -
time, kV and mA values - which can be selected by
pressing these keys. There are ten sets of parameters for
both the child mode and the adult mode: one for each
exposure region and one for default exposure values,
which are in use when an exposure region is not selected.
The selections that can be made are: molars, premolars &
canines, incisors, occlusal exposure, endodontic and bite-
wing.
Press the desired key once to select the projection of the
maxilla. The indicator light of the selected projection will
come on.
Press the key twice to select the projection of the
mandible. The indicator light of the selected projection will
come on.
Pressing the key a third time will recall the default
exposure values.
The preprogrammed settings can be changed by the user,
see section 16.1 “Programming default exposure values”
on page 36.
8.2.2 Adult/child mode selection key and indicator light
Press the adult/child mode selection key once to select the
child mode. The indicator light of the child mode will come
on.
Press the key again to return to the adult mode. The
indicator light of the adult mode will come on.
Incisors
Premolars
and
canines
Molars
Occlusal
exposure
Adult/
child
mode
Endo-
dontic
Bite-wing
