B4
CV JOINT - BTB
MAGNUM 325 4X4 A00CD32AA and MAGNUM 325 4X4 A00CD32CA and 325 MAGNUM 4X4 HDS A00CD32FA and 325 MAGNUM 4X4 HDS II A00CD32FB
BTB
10
1
2
3
4
5
6
7
8
9
12
11
13
Ref. Part No. Qty. Description Ref. Part No. Qty. Description
1 1380119 2 Asm., CV Housing w/Sleeve
2 5222299 1 Sleeve, Drive Shaft Seal
3 3260115 1 Clamp, CV Joint, Large
4 7670091 1 Circlip
5 5411106 1 Boot, CV Joint
6 1380094 1 Shaft Replacement (Incl. 4)
7 1380092 1 Cardan Replacement (Incl. 4,6,8,9)
8 2200771 1 Kit - Cross and Bearing
9 3260130 1 Yoke, Splined
10 7661913 1 Pin, Spring
11 7080627 1 Clamp, Small Band
12 2200773 1 Kit - Boot Replacement, CV Joint
(Incl. 3,5,11)
13 2200961 1 Kit - Drive Shaft w/Sleeve
11/98
