C13
GEARCASE SELECTOR MOUNTING
MAGNUM 325 4X4 A00CD32AA and MAGNUM 325 4X4 A00CD32CA and 325 MAGNUM 4X4 HDS A00CD32FA and 325 MAGNUM 4X4 HDS II A00CD32FB
1
2
11
9
12
4
3
5
7
13
2
2
6
6
2
9
10
8
Ref. Part No. Qty. Description Ref. Part No. Qty. Description
1 7061013 2 Rod End, LH
2 7546707 4 Nut, FLEXLOC
3 7546702 2 Nut, LH
4 5020974 1 Rod, Low
5 7546701 2 Nut
6 7061014 2 Rod End, RH
7 1012822-067 1 Bracket, Shifter
8 7512130 2 Screw
9 7542122 4 Nut, Nylok
10 7555827 2 Washer
11 7512126 2 Bolt
12 7517386 4 Screw
13 5020973 1 Rod, High, Rev
10/00
