8.32
9929375 R02 - 2016-2019 GENERAL / GENERAL 4 Service Manual
© Copyright Polaris Industries Inc.
5. Keep a magnet close to catch ball and spring when
the round adjuster is almost out.
6. Remove the dust boot.
7. Remove both retaining rings from the eyelet and
press out bearing.
DX BUSHING AND SEAL STYLE EYELET
NOTICE
DX Bushing style eyelets have larger bore diameters
than conventional eyelets.
1. Remove both dust seals from the eyelet.
2. Press out DX bushing using DX Bushing Press Kit.
3. Remove dust seal from bearing cap.
NOTICE
On some models the seal may be in the bearing
assembly.
STEERING / SUSPENSION
