8.54
9929375 R02 - 2016-2019 GENERAL / GENERAL 4 Service Manual
© Copyright Polaris Industries Inc.
5. Install wheels and torque lugs to specification.
TORQUE
Wheel Nuts:
120 lb-ft (163 Nm)
STABILIZER BAR REMOVAL - REAR
1. Lift and support vehicle by main frame.
2. Remove wheels.
3. Identify / mark top side of the stabilizer bar to
reference during installation.
4. Remove the fasteners
q
retaining the stabilizer bar
to the linkage. Repeat step for opposite side.
5. Mark the location and remove the two stabilizer bar
mounts (if replacing stabilizer bar).
6. Remove the fasteners
w
retaining the stabilizer bar
mounts / bushings to the vehicle frame.
7. Carefully remove the stabilizer bar from the vehicle.
8. Inspect the stabilizer bar for straightness. Inspect the
pivot bushings and replace if needed.
STEERING / SUSPENSION
