9929375 R02 - 2016-2019 GENERAL / GENERAL 4 Service Manual
© Copyright Polaris Industries Inc.
10.55
11. Install the fasteners holding the front fender to the
vehicle. Torque the fasteners to specification.
TORQUE
Front Fender Fasteners:
3.5 lb-ft (4.7 Nm)
12.Install the fastener holding the front fender flair to the
front fender. Torque the fastener to specification.
TORQUE
Front Fender Flair Fastener:
3.5 lb-ft (4.7 Nm)
13.Install the hood onto the vehicle. Refer to “Hood
Installation”page 10.56 procedure.
FRONT BUMPER INSTALLATION
1. Install the front bumper on the vehicle and align
mounting points. Install the front bumper lower
mounting fasteners and torque to specification.
TORQUE
Front Bumper Fasteners:
30 lb-ft (41 Nm)
2. Install the front bumper upper mounting fasteners and
torque to specification.
TORQUE
Front Bumper Fasteners:
30 lb-ft (41 Nm)
BODY / FRAME
