Primary Main Jet
Secondary Main Jet
Mid Range Jet
Pilot Jet
Fuel / Exhaust
4.1
2002 Freedom / V irage Carburetor Specifications
Carburetor Manufacture Keihin
Size 40mm / 38mm V enturi
Fuel Regulator System Diaphragm
Float Arm Level 1.5mm
Starter System Choke
Main System Primary Main Jet: 148
Secondary Main Jet: 120
Mid Range System #42
Pilot System #58
Low Speed Screw 1 3/4 Turns Out From Lightly Seated
Idle Speed (In Water) 1350±100
Needle & Seat Pop Off Pressure 18 -- 21 PSI
V alve Spring 26 Grams
2002 Freedom / Vir age Jet Locations
