Apply Marine Grade
Silicone Sealant PN
8560054
Thru--Hull Fitting
Pitot Tube
Final Drive / Propulsion
5.14
Pump Assembly / Installation
1. If pump housing was removed, begin by re--attaching
to the hull. Refer to pages: 5.5 and 5.8 for bolt torque.
NOTE: Completely remove all old silicone from hull and
parts prior to installation.
1. Prior to pump installation, inspect the thru--hull fitting
and pump inlet housing. Look for any cracks or hull
damage. Verify that the pitot tube is level and pointing
towards the front of the watercraft.
2. Piece together pump in the order that it was removed.
Apply anti--seize lubricant to pump
component mating surfaces.
