General Information
1.17
2002 Genesis i
Model Number
W025098D
Engine
Platform Polaris Marine 1200 DIt
Engine Model Number W120--DFI--04A
Engine Displacement 1165cc
Number of Cylinders 3
Bore & Stroke (mm) 84x70
Compression Ratio (Full Stroke) 6.5/6.5/6.2:1 (MAG, CTR, PTO)
Maximum Horsepower 135
Maximum Torque 110 ft.lbs.
Cooling System Water Cooled / Thermostat Pop--Off, self--draining, Direct From Propulsion.
Thermostat Opening Temperature 143°F(62°C)
Overheat Warning S.L.O.W . (Warning Light, RPM Limit)
Induction Type Case Reed
Lubrication Oil Injected
Oil Requirements Polaris TC--W3
RPM Limiter 7200 RPM
Exhaust System Linear Power Manifold
Sound Reduction PLANETt
Carburetion
Fuel Delivery (3) Injectors (DIt)
Fuel Requirement 87 Non--Oxygenated / 89 Oxygenated
Idle Speed (In Water) 1 150 RPM
Electrical
Ignition System EMM (Engine Management Module)
Magneto Generator Output 12A / 160W @ 4500 RPM
Spark Plug NGK PZFR6H
Spark Plug Gap .028 -- .032 (.7 -- .8mm)
Timing Degrees BTDC Controlled By EMM
Battery 12 Volts / 19 Amps
Circuit Breaker / (Fuses) (2)15A Circuit Breakers (2A MFI, 3A Bilge Located within electrical splice blocks)
Starting Electric (One button start/stop)
Propulsion
Jet Pump Type Dominator Short, Single Stage Axial Flow w/Six V ane Stainless Steel Stator
Impeller Rotation Counter Clockwise (From Aft)
Coupling Type Rubber Coupler
Minimum Depth For Operation 2 ft. (60cm.)
Pivoting Angle 30°
Impeller Type Progressive Pitch Radial Blade
Impeller Diameter 5.8 in.
Reverse System PERCt (Polaris Electronic Reverse Control)
Hull/Body
Hull Design Modified Full V
Hull Material FRC (Fiberglass Reinforced Composite)
Top Deck Material FRC (Fiberglass Reinforced Composite)
