Electrical Systems
7.21
Multi--Function Instrument (MFI) -- Continued
VOLTMETER: The left side of the multi-purpose display contains the battery VOLTMETER. Battery voltage is
displayed from 5 to 18 volts in .1 volt increments. A battery voltage of less than 10.9 volts will trigger the LOW
POWER warning message, indicating battery voltage is approaching a no start condition.
DISTANCE METER: The center of the MFI contains a resettable DIST ANCE METER. Distance is displayed from
0-999.9 miles (0-999.9 km) in .1 increments. To reset the DIST ANCE METER, simply press and hold the DIST ANCE
RESET button until the distance displayed returns to 000.0.
HOUR METER: The right side of the multi-purpose display contains the engine HOUR METER. Actual engine
operating hours are displayed in .1 hour increments from 0-999.9 hours. The HOUR METER cannot be reset,
and is retained even when power is removed due to non-volatile EEPROM memory.
SPEEDOMETER: The right side of the MFI contains an analog speedometer. While the speedometer is tradition-
al in appearance, it is actually controlled by the system microprocessor , and is extremely accurate.
DIRECTION: The lower portion of the analog display contains a forward/reverse direction indicator. The pointer
on the gauge moves in synchronization with the reverse gate as it is lowered over the jet nozzle when actuated
by the electric thumb switch. The indicator is useful in establishing a neutral position between forward and re-
verse. The LED will flash when the reverse gate is not fully forward. Pressing any key will disable the LED for
five minutes.
SECURITY LOCK: Briefly pressing and releasing the LOCK button will cause the lock status to be displayed,
either LOCKED or UNLOCKED. Pressing and holding the LOCK button for several seconds initiates the SE-
CURITY LOCK function. The MFI will display ENTER CODE----. Enter the code using the 5-button keypad. The
factory set default code is 1234. An asterisk (*) will appear with each press of a numeric button. If the proper
code has been entered, the display will show the new lock status. If previously LOCKED, the security lock will
switch to UNLOCKED, and the vehicle may be started normally. If previously UNLOCKED, the security lock will
switch to LOCKED and the vehicle will not start.
If starting the engine is attempted while the security lock is set to LOCKED, the warning LED will flash, the engine
will not start, and the MFI will indicate LOCKED, followed by ENTER CODE----. If an improper code is entered,
the MFI will display INVALID CODE, and exit code entry mode.
CODE SET MODE: The factory set default security code is 1234, however, the code may be changed to any
4 digit number. To select your own code, enter CODE SET mode by pressing and continuing to hold the LOCK
button for several seconds until CHANGE CODE is displayed (the display will first show the lock status, followed
by ENTER CODE----, and finally CHANGE CODE). The MFI will then display OLD CODE----. Enter the code
as if locking or unlocking the vehicle. If the correct code is entered, the display will then show NEW CODE----.
Select any 4-digit code. The display will then read CONFIRM CODE----. Enter the same code to confirm your
selection. CODE CONFIRMED will display for several seconds if the second entry of the new code matches the
first. If the second code entered does not match the first, INVALID CODE will be displayed and the CODE SET
MODE is cancelled.
