Polaris WATERCRAFT Virage TXi User Manual

Engine / Cooling
3.1
2002 Freedom / Virage
Engine Model Number W70--SCSP--05A
Cylinder Displacement (cc) 701cc
Bore Inches / (mm) 3.189in. (81mm)
Stroke 2.677in. (68mm)
Cylinder Head Volume (Uninstalled) 39.2cc
Cylinder Head Volume (Installed) 31.9cc
Piston--To--Cylinder Clearance Inches (mm) .0055 -- .0065 (.14 -- .16mm)
Limit: .010in. (.25mm)
Ring End Gap Inches (mm) .014 -- .019 (.36 -- .48mm)
Maximum Horsepower 95
Maximum Torque 69.2
Oil Requirement Polaris TC--W3
RPM Limiter 7200 RPM
Compression (Sea Level) 120 -- 150 lbs./sq.in. (8.40 -- 10.5 kg/sq. in.)
No greater than 5% between cylinders.
2002 Virage TX
Engine Model Number W120 -- TCSP -- 04A2
Cylinder Displacement (cc) 1165cc
Bore mm / (Inches) 84 (3.307)
Stroke mm / (Inches) 70 (2.756)
Cylinder Head Volume Uninstalled 46.5cc ± .5cc
Cylinder Head Volume Installed 36.5cc
Piston--To--Cylinder Clearance Inches .0068in. ± .0006in. (Production Tolerance)
Ring End Gap Inches .019in. ± .003in.
Maximum Horsepower 135
Maximum Torque 110
Oil Requirement Polaris TC--W3
RPM Limiter 7200 RPM
Compression (Sea Level) 120 -- 150 lbs./sq.in. (8.40 -- 10.5 kg/sq. in.)
No greater than 5% between cylinders.
2002 Genesis
Engine Model Number W120--TCSP--04A1
Cylinder Displacement (cc) 1165cc
Bore mm / (Inches) 84 (3.307)
Stroke mm / (Inches) 70 (2.756)
Cylinder Head Volume Uninstalled 46.5cc ± .5cc
Cylinder Head Volume Installed 38.9cc
Piston--To--Cylinder Clearance Inches .0068in. ± .0006in. (Production Tolerance)
Ring End Gap Inches .019in. ± .003in.
Maximum Horsepower 135
Maximum Torque 110
Oil Requirement Polaris TC--W3
RPM Limiter 7200 RPM
Compression (Sea Level) 120 -- 150 lbs./sq.in. (8.40 -- 10.5 kg/sq. in.)
No greater than 5% between cylinders.
