Polaroid Joshua Vision

3 - 11
JOSHUA TEST
COVER
AMBIENT TRIM
WHEEL
4. If the STOP ERROR display readings are not within specifications, adjust the Ambient Calibration
wheel (Figure 3-6) with a dental pick. Rotate wheel clockwise (CW) to decrease exposure or counter
clockwise (CCW) to increase expoxure.
5. Retest the camera. If necessary, repeat this calibration procedure until Ambient exposure is
correct.
Figure 3-6. Ambient/Strobe Exposure Adjustments
STROBE TRIM
WHEEL
JOSHUA HORN
ASSEMBLY
CAMERA
