Polaroid Joshua Vision User Manual

4 - 12
Bottom Door Assembly
1. Removal
a. Using a narrow blade flat screwdriver or tweezers, lift out the pins (Figure 4-8) that hinge the
Bottom Door Assembly to the Main Body of the Camera.
b. Gently Squeeze the Pack Frame together to disconnect it from the Door Stops on the Main Body
of the camera. Lift out the Bottom Door Assembly.
Figure 4-8. Removal of Bottom Door Assembly
2. Disassembly
a. Gently squeeze and push inward the Picture Removal Door (Figure 4-9) to release it from the
plastic hinge posts of the Bottom Door Assembly. Lift out the Picture Removal Door.
Figure 4-9. Removal of Picture Removal Door from Bottom Door
DOOR STOP
BOTTOM DOOR
HINGE
PIN
HINGE
PIN
MAIN BODY
REMOVAL
DOOR
PLASTIC
HINGE
POST
PLASTIC HINGE
