Polaroid Joshua Vision

4 - 17
2. Reassembly
To reassemble the Top Cover, follow the removal steps in reverse order.
Note: When reassembling the Top Cover (Figure 4-17) make sure:
• Top Cover Springs are inserted into the grooves on the Main Body of the camera.
• Hinge pins are properly installed.
- Long pin into left side
- Short pin into right side
Figure 4-17. Installation of Top Cover
LONG PIN (LEFT SIDE)
TOP COVER SPRING
SHORT PIN (RIGHT SIDE)
