4 - 18
Shutter Assembly
1. Removal
a. Using a narrow blade flat screwdriver, push aside the end of the rubber Flapper to access the
Shutter Link pin (Figure 4-18) and then push the pin out.
b. Using needlenose pliers, pull out the Shutter Link pin to release the top portion of the
Shutter Link from the Shutter Assembly.
Figure 4-18. Removal of Shutter Link Pin
c. Using a solder aid stick, gently pry up the corner of the Shutter Decorative Plate
(Figure 4-19) to release it from the Shutter Assembly. Lift off the Shutter Decorative Plate.
.
Figure 4-19. Removal of Shutter Decorative Plate
SOLDER AID
TOOL
SNAP
RUBBER FLAPPER
END OF FLAPPER
LINK PIN
REMOVE
SHUTTER
DECORATIVE
PLATE
