4 - 10
Bottom Chute Cover
1. Disassembly (Figure 4-6)
a. Remove Neck Strap from the screw posts.
b. Using tweezers, remove the Door Latch Return Spring from the Door Latch and the Bottom
Chute Cover.
c. Using a narrow blade flat screwdriver, gently pry up the Door Latch locking tab to release it
from theBottom Chute Cover. Lift off the Door Latch.
Figure 4-6. Disassembly of Bottom Chute Cover
2. Reassembly
To reassemble the Bottom Chute Cover, follow the disassembly steps in reverse order.
DOOR LATCH
LOCKING TAB
DOOR LATCH
BOTTOM CHUTE
COVER
DOOR LATCH
RETURN SPRING
