4 - 6
c. Using a solder aid tool, gently pry up the light/dark Trim Button to release it from the Rear
Panel. Lift off the Trim Button.
d. Using a solder aid tool, gently pry the plastic locking tab of the Control Panel Decorative Plate
to release it from the Rear Panel. Lift off the Control Panel Decorative Plate being careful not
to loose the counter Window (Lens).
Note: The Counter Window (Lens) will fall out as the Control Panel Decorative Plate is
removed.
Figure 4-2. Disassembly of Rear Panel
SELF TIMER
RETURN SPRING
SELF TIMER
BUTTON
PLASTIC LOCKING
TAB
LIGHT/DARK
TRIM BUTTON
REAR PANEL
COUNTER
WINDOW (LENS)
CONTROL PANEL
DECORATIVE PLATE
FLAT SURFACE OF
COUNTER WINDOW
(LENS) FACES
BOTTOM OF
DECORATIVE PLATE
