User Guide for the SoundPoint IP 650 Desktop Phone
1 - 8
If your phone is not part of a large deployment, it may not be registered after
you set it up. Before you use your phone, you or your system administrator
will have to register it.
For detailed information on how to register your phone after you install it,
refer to Quick Tip 44011 Registering Standalone SoundPoint IP, SoundStation IP,
and Polycom VVX Phones, available from
http://www.polycom.com/usa/en/support/voice/soundpoint_ip/VoIP_T
echnical_Bulletins_pub.html .
Using the Polycom Web Configuration Utility
This user guide explains how to update phone settings from your phone, using
your phone’s menu system. If you want, you can update these settings
remotely with the Polycom Web Configuration Utility.
The phone’s Web Configuration Utility enables you to view and configure
phone behavior from a computer using any compatible Web browser. The
utility provides a browser-friendly view of your phone’s current settings.
Using the utility, you can perform the same updates from your computer that
you can perform using your phone’s menu system.
You can access the utility using any compatible Web browser. Before you
begin, you’ll need to know the IP address of your phone, and the user name
and password login credentials of the phone user or the phone administrator.
To access the Web Configuration Utility for your phone:
1 Launch the compatible Web browser from a computer on the same
network as your phone. The supported browsers are:
Microsoft Internet Explorer (version 7.0 and higher)
Mozilla Firefox (version 3.0.X and higher)
Apple Safari (version 5 and higher)
Google Chrome
2 In the Address Bar of your Web Browser, enter the IP address of your
phone.
The IP address is four sets of numbers separated by periods. For example,
if your phone’s IP address is 123.22.3.4, enter 123.22.3.4 in the address bar.
3Press the Enter key.
Note
For detailed information on accessing, navigating, and using the utility, see the
Polycom Web Configuration Utility User Guide, available from the Technical
Bulletins Support page

Table of Contents

Other manuals for Polycom SoundPoint IP 650

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Polycom SoundPoint IP 650 and is the answer not in the manual?

Polycom SoundPoint IP 650 Specifications

General IconGeneral
Full duplexYes
Camera includedNo
Frequency range150 - 7000 Hz
Base station keys26 + 4
Channels quantity2 channels
Dimensions (WxDxH)265 x 150 x 190 mm
Networking featuresDHCP/Static IP
Ethernet LAN (RJ-45) ports2
Supported network protocolsFTP, TFTP, HTTP, HTTPS
Supported data transfer rates10/100 Mbit/s
Product colorGray
Volume controlDigital
Voice codecsG.722
Display resolution320 x 160 pixels
Display number of colorsMonochrome
Storage temperature (T-T)-40 - 70 °C
Operating temperature (T-T)10 - 40 °C
Operating relative humidity (H-H)20 - 85 %
Power requirements24V DC / 500mA
SafetyUL 60950-1;CE Mark;CAN/CSA-C22.2 No. 60950-1-03;EN 60950-1;IEC 60950-1;AS/NZS 60950-1
Certification- FCC Part 15 (CFR 47) Class B - ICES-003 Class B - EN55022 Class B - CISPR22 Class B - AS/NZS CISPR 22 Class B - VCCI Class B - EN55024 - EN61000-3-2; EN61000-3-3 - ROHS
Weight and Dimensions IconWeight and Dimensions
Weight1260 g
Package weight2045 g
