Using the Basic Features of Your Phone
2 - 23
A valid speed dial index is any unused number from 1 to 9999.
6. Press the Save soft key to accept your changes.
7. Press to return to the idle screen.
To assign a new speed dial key:
1. Press and hold an unassigned .
A new empty entry in the contact directory is automatically opened
allowing contact information to be added.
2. (Optional.) Enter contact information.
Use the 1/A/a soft key to select between numeric and upper/lower case
alphanumeric modes.
Use the Encoding soft key to access special characters in other languages.
3. Enter a contact number.
The number must be unique (not already in the directory).
4. Change the Speed Dial Index field.
The index can be any value between the next available index value and the
maximum (value of 9999).
5. Press the Save soft key to accept your changes.
6. Press to return to the idle screen.
Using Voice Mail
You can access voice mail messages from your phone (if enabled). Your voice
mail is saved in a centralized location.
Polycom recommends that you assign speed dial index values consecutively.
For example, if you assign the third Line Key to the speed dial index value “2”,
assign the fourth Line Key to the speed dial index value “3”.
Note
Voice mail is an optional feature configured on the call server and may not be
supported on your particular system. For more information, contact your system
administrator.
Screen options may vary with your application. Voice mail may be accessible with a
single key press. Contact your system administrator about this option.

Table of Contents

Other manuals for Polycom SoundPoint IP 650

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Polycom SoundPoint IP 650 and is the answer not in the manual?

Polycom SoundPoint IP 650 Specifications

General IconGeneral
Full duplexYes
Camera includedNo
Frequency range150 - 7000 Hz
Base station keys26 + 4
Channels quantity2 channels
Dimensions (WxDxH)265 x 150 x 190 mm
Networking featuresDHCP/Static IP
Ethernet LAN (RJ-45) ports2
Supported network protocolsFTP, TFTP, HTTP, HTTPS
Supported data transfer rates10/100 Mbit/s
Product colorGray
Volume controlDigital
Voice codecsG.722
Display resolution320 x 160 pixels
Display number of colorsMonochrome
Storage temperature (T-T)-40 - 70 °C
Operating temperature (T-T)10 - 40 °C
Operating relative humidity (H-H)20 - 85 %
Power requirements24V DC / 500mA
SafetyUL 60950-1;CE Mark;CAN/CSA-C22.2 No. 60950-1-03;EN 60950-1;IEC 60950-1;AS/NZS 60950-1
Certification- FCC Part 15 (CFR 47) Class B - ICES-003 Class B - EN55022 Class B - CISPR22 Class B - AS/NZS CISPR 22 Class B - VCCI Class B - EN55024 - EN61000-3-2; EN61000-3-3 - ROHS
Weight and Dimensions IconWeight and Dimensions
Weight1260 g
Package weight2045 g
