Polycom SoundPoint IP 650 User Manual

User Guide for the SoundPoint IP 650 Desktop Phone
2 - 22
In the figure below, the phone has one line key, and speed dial keys for Byron,
Lauren, and Andrew. To dial Byron, Lauren, or Andrew, press the associated
line key.
Assigning New Speed Dial Keys
To add or edit a speed dial index for an existing contact:
1. Press .
2. Select Contact Directory.
3. Scroll to highlight the contact.
You can also use the * key to page up and the # key to page down.
4. Press the Edit soft key.
5. Do one of the following:
— Enter the next available speed dial index.
— Delete the existing speed dial index by using , and then enter a
new speed dial index.
Note
To quickly access a list of speed dial index numbers, press the Up Arrow key from
the idle screen. To speed dial a contact, press the Up Arrow key followed by the
contact’s speed dial index. For example, if Joan’s speed dial index is 55, pressing
the Up Arrow key followed by 55 will place a call to Joan.

Polycom SoundPoint IP 650 Specifications

General

Full duplex	Yes
Camera included	No
Frequency range	150 - 7000 Hz
Base station keys	26 + 4
Channels quantity	2 channels
Dimensions (WxDxH)	265 x 150 x 190 mm
Networking features	DHCP/Static IP
Ethernet LAN (RJ-45) ports	2
Supported network protocols	FTP, TFTP, HTTP, HTTPS
Supported data transfer rates	10/100 Mbit/s
Product color	Gray
Volume control	Digital
Voice codecs	G.722
Display resolution	320 x 160 pixels
Display number of colors	Monochrome
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	10 - 40 °C
Operating relative humidity (H-H)	20 - 85 %
Power requirements	24V DC / 500mA
Safety	UL 60950-1;CE Mark;CAN/CSA-C22.2 No. 60950-1-03;EN 60950-1;IEC 60950-1;AS/NZS 60950-1
Certification	- FCC Part 15 (CFR 47) Class B - ICES-003 Class B - EN55022 Class B - CISPR22 Class B - AS/NZS CISPR 22 Class B - VCCI Class B - EN55024 - EN61000-3-2; EN61000-3-3 - ROHS

Weight and Dimensions

Weight	1260 g
Package weight	2045 g
