Polycom SoundPoint IP 650 User Manual

User Guide for the SoundPoint IP 650 Desktop Phone
3 - 16
This section includes information on:
• Browsing Recorded Calls
• Playing Back Recorded Calls
• Answering a Call While Playing Back Recorded Calls
Browsing Recorded Calls
To browse the recorded files:
1. Press .
2. Select Features > Removable Storage Media > Browse Recordings...
You can rename, delete, or open and open the selected .wav file by
pressing the Rename, Delete, or Open soft keys.
3. Press to return to the idle display.
Polycom recommends that you do not remove the USB flash drive while playing
back files. There is a small probability that the USB flash drive itself may be
damaged by this action.

Polycom SoundPoint IP 650 Specifications

General

Full duplex	Yes
Camera included	No
Frequency range	150 - 7000 Hz
Base station keys	26 + 4
Channels quantity	2 channels
Dimensions (WxDxH)	265 x 150 x 190 mm
Networking features	DHCP/Static IP
Ethernet LAN (RJ-45) ports	2
Supported network protocols	FTP, TFTP, HTTP, HTTPS
Supported data transfer rates	10/100 Mbit/s
Product color	Gray
Volume control	Digital
Voice codecs	G.722
Display resolution	320 x 160 pixels
Display number of colors	Monochrome
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	10 - 40 °C
Operating relative humidity (H-H)	20 - 85 %
Power requirements	24V DC / 500mA
Safety	UL 60950-1;CE Mark;CAN/CSA-C22.2 No. 60950-1-03;EN 60950-1;IEC 60950-1;AS/NZS 60950-1
Certification	- FCC Part 15 (CFR 47) Class B - ICES-003 Class B - EN55022 Class B - CISPR22 Class B - AS/NZS CISPR 22 Class B - VCCI Class B - EN55024 - EN61000-3-2; EN61000-3-3 - ROHS

Weight and Dimensions

Weight	1260 g
Package weight	2045 g
