Polytec PSV-I-500 User Manual

2-3
2 Introduction
2.2.2 Decoders
Only digital velocity decoders are used in the PSV-500-3D. This enables very
precise and high-resolution acquisition of vibrations. With the H system the
decoder signals are directly transmitted digitally to the PC. With the M system
the signals are converted into analog signals and transmitted to the data
acquisition board of the PC.
The decoders are equipped with digital tracking filters which allow robust
measurements even if the optical signals are weak.
DV-04 With 14 measurement ranges, the DV-04 velocity decoder covers the
frequency range from 0 Hz to 2 MHz. This is the standard decoder of the
PSV-500-3D-M.
2.3 Setup and Properties
The decoder in the front-end as well as the data acquisition board determine
the metrological properties of the PSV. Depending on the application, there
are different models available. Their properties are summarized in the
following tables.
Table 2.1: Overview of PSV model 3D-M
Component/Properties PSV-500-3D-M (Standard) PSV-500-3D-M (Xtra)
Junction box PSV-E-500 PSV-E-500
Front-End PSV-F-500-3D-M PSV-F-500-3D-M
Velocity decoder DV-04 DV-04
Measurement ranges [mm/s] 14 ranges, 1 to 12000 14 ranges, 2.5 to 30000
Maximum frequency
1 MHz (2 MHz)
1
1
The specifications in brackets are available as an option.
1 MHz (2 MHz)
1
PC PSV-W-500-M PSV-W-500-M
Data acquisition PCI-6110 PCI-6110
Reference channels 1 1
Maximum bandwidth
1 MHz (2 MHz)
1
1 MHz (2 MHz)
1
Function generator M2i.6030 M2i.6030
Output channels 1 1
Maximum bandwidth
1 MHz (2 MHz)
1
1 MHz (2 MHz)
1
