User manual Pomac PLP Lobe pump

10 CE/PLP (1406) EN-12

The codes at pos. .. determine the position of the suction connection.

For horizontal pump position:

For vertical pump position:

R = suction position at right hand side, seen from shaft end.

T = suction position = top

L = suction position at left hand side, seen from shaft end.

B = suction position = bottom

4. Connection type discharge side

01 = hygienic thread acc. to DIN 11851

02 = SMS 1145

03 = Tri-Clamp DIN32676

04 = Aseptic thread DIN 11864-1

05 = Aseptic flange DIN 11864-2

06 = flanges acc. to EN1092-1

07 = BSP-thread

08 = NPT-thread

09R = rectangular flange right side as seen from shaft end

09L = rectangular flange left side as seen from shaft end

10 = Aseptic Tri-Clamp DIN 11864-3

xx = acc. to client specification

5. Type shaft seal

M1 = single mechanical seal SiC/SiC

M2 = double mechanical seal quench or flush SiC/SiC - SiC/SiC

M3 = single mechanical seal with small seal faces SiC/SiC

M4 = single mechanical seal TC/TC

M4V = retracted single mechanical seal TC/TC

M5 = double mechanical seal quench or flush TC/TC - TC/TC

M6 = double mechanical seal quench or flush TC/TC - SiC/SiC

M7 = double mechanical seal quench or flush SiC/SiC - TC/TC

O1 = single O-ring, stainless steel shaft sleeve

O2 = double O-ring with quench, stainless steel shaft sleeve

L3 = WDR PTFE lip seal, ceramic coated stainless steel shaft sleeve

6. Elastomers shaft seal

E = EPDM acc. FDA & EC1935/2004

V = Viton acc. FDA & EC1935/2004

T = Teflex FEP/VITON acc. FDA & EC1935/2004

K = FFKM acc. FDA & EC1935/2004

N = NBR

S = Silicone

X = acc. to client specification

7. Elastomers static O-rings
