9.5.4. Part list with article numbers PLP 3
ITEM.
QUANTITY
DESCRIPTION
ARTICLE NR.
PLP 3-2
PLP 3-3
PLP 3-4
001
4
Cap nut
051.022-16-000-5
051.022-16-000-5
051.022-16-000-5
002
4
Stud
051.073-16-045-5
051.073-16-045-5
051.073-16-045-5
003
1
Front cover
700.317-000
700.317-000
700.317-000
004
1
O-Ring Pump cover EPDM
051.741-100042
051.741-100042
051.741-100042
O-Ring Pump cover FKM
051.760-100042
051.760-100042
051.760-100042
005
2
Rotor retainer
700.318-000
700.318-000
700.318-000
006
2
O-Ring Lobe bolt EPDM
051.741-100014
051.741-100014
051.741-100014
O-Ring Lobe bolt FKM
051.760-100014
051.760-100014
051.760-100014
007
**shaft seal**
008
2
Seal cover
700.350-007
700.350-007
700.350-007
009
12
Allen screw
051.000-06-012-5
051.000-06-012-5
051.000-06-012-5
010
2
Oil retaining ring
P-000-006-712
P-000-006-712
P-000-006-712
011
1
Gasket gearbox cover
P-000-006-488
P-000-006-488
P-000-006-488
012
4
Shim
700.360-000
700.360-000
700.360-000
013
2
Cone bearing
051.658-060-012
051.658-060-012
051.658-060-012
014
8
Allen screw
051.000-12-060-5
051.000-12-060-5
051.000-12-060-5
015
2
Bearing cartridge
700.315-000
700.315-000
700.315-000
016
2
Cone bearing
051.658-050-011
051.658-050-011
051.658-050-011
017
1
Right hand gear
700.320-000
700.320-000
700.320-000
018
2
Key
051.607-14-043-10
051.607-14-043-10
051.607-14-043-10
019
2
Tab washer
051.670-045-000
051.670-045-000
051.670-045-000
020
2
Lock nut
051.669-045-000
051.669-045-000
051.669-045-000
021
1
Oil retaining ring
051.763-024
051.763-024
051.763-024
022
1
Key
051.607-12-060-00
051.607-12-060-00
051.607-12-060-00
023
1
Drive shaft
700.313-001
700.313-000
700.313-002
024
1
Oil sight glass
054.210-012
054.210-012
054.210-012
025
1
Oil fill plug with breather
054.211-011
054.211-011
054.211-011
026
2
Cylindrical pin
051.074-080-012-6
051.074-080-012-6
051.074-080-012-6
027
2
Plug
054.108-032-3
054.108-032-3
054.108-032-3
028
1
Gearbox cover
700.316-000
700.316-000
700.316-000
029
1
Left hand gear
700.321-000
700.321-000
700.321-000
030
1
Lay shaft
700.314-001
700.314-000
700.314-002
031
4
Allen screw
051.000-12-080-5
051.000-12-080-5
051.000-12-080-5
032
2
Foot
700.332-000
700.332-000
700.332-000
033
4
Allen screw
051.000-12-030-5
051.000-12-030-5
051.000-12-030-5
034
1
Rotor casing
700.310-014
700.310-000
700.310-015
035
2
Rotor Bi-Wing
700.311-004
700.311-000
700.311-001
Rotor Bi-Wing Clearance class C1
P-000-004-951
P-000-004-953
P-000-004-955
Rotor Bi-Wing Clearance class C2
P-000-004-952
P-000-004-954
P-000-004-956
Rotor Quattro
700.311-006
700.311-007
700.311-008
Rotor Quattro Clearance class C1
P-000-004-975
P-000-004-976
P-000-004-977
