9.5.2. Part list with article numbers PLP 15
ITEM.
QUANTITY
DESCRIPTION
ARTICLE NR.
PLP 15-2
001
4
Cap nut
051.022-10-000-5
002
4
Stud
P-000-001-527
003
1
Front cover
700.517-000
004
1
O-Ring Pump cover EPDM
P-000-001-524
O-Ring Pump cover FKM
P-000-001-793
005
2
Rotor retainer
700.118-000
006
2
O-Ring lobe bolt EPDM
051.741-100000
O-Ring lobe bolt FKM
051.760-100000
007
**shaft seal**
008
2
Seal cover
700.150-007
009
8
Allen screw
051.000-04-012-5
010
2
Oil retaining ring
P-000-001-523
011
1
Gasket gearbox cover
P-000-006-355
012
4
Shim
700.560-xxx
013
2
Cone bearing
P-000-003-735
014
8
Allen screw
051.000-08-035-5
015
2
Bearing cartridge
700.515-000
016
2
Cone bearing
P-000-001-503
017
1
Right hand gear
700.520-000
018
2
Key
019
2
Tab washer
P-000-001-526
020
2
Lock nut
P-000-001-525
021
1
Oil retaining ring
P-000-001-522
022
1
Key
051.607-06-040-02
023
1
Drive shaft
700.513-000
024
1
Oil sight glass
054.210-012
025
1
Oil fill plug with breather
054.211-011
026
2
Cylindrical pin
051.074-050-010-6
027
2
Plug
054.108-031-3
028
1
Gearbox cover
700.516-000
029
1
Left hand gear
700.521-000
030
1
Lay shaft
700.514-000
031
4
Allen screw
051.000-06-040-5
032
2
Foot
700.132-004
033
4
Allen screw
051.000-10-025-5
034
1
Rotor casing
700.510-000
035
2
Rotor Bi-Wing
700.511-000
Rotor Bi-Wing Clearance class C1
P-000-005-005
Rotor Bi-Wing Clearance class C2
P-000-005-006
Rotor Quattro
700.511-001
Rotor Quattro Clearance class C1
P-000-005-009
Rotor Quattro Clearance class C2
P-000-005-010
