User manual Pomac PLP Lobe pump
16 CE/PLP (1406) EN-12
⚫ In case a single pump must be hoisted, fix the straps as follows:
4.4. Safety
Never insert fingers into the rotor case or into the connection ports. Even manually
rotating the shaft can cause injury!
! If the risk exists of exceeding the maximum working pressure a safety device must be
fitted to the pump, the drive or the system!
4.5. Foundation
⚫ The foundation must be solid, flat and level.
⚫ Take into consideration the need for draining facilities.
⚫ The entire weight of the baseplate should rest level on the foundation. The baseplate may
not bend!
4.6. Built-in dimensions
⚫ The proper built-in dimensions of the pump are incorporated in the dimensions sketch,
supplied separately with the pump (-unit).
⚫ See paragraph 9.2 for the main dimensions of the single pump.
