Hardware Configuration
RUBY-9715VG2AR User’s Manual 2-5
J5 : PS/2 Keyboard/Mouse Connector
PIN No. Signal Description
7 Mouse Data
1 Keyboard Data
3,9 Ground
4 5V Dual
2,6,8,12 N/C
11 Mouse Clock
5 Keyboard Clock
J6 : Primary USBx2 + LAN Connector
PIN No. Signal Description PIN No. Signal Description (Top Con.)
1 MDI0+ (MDI0P) 1 5V Dual
2 MDI0- (MDI0N) 2 USB0-
3 MDI1+ (MDI1P) 3 USB0+
4 MDI2+ (MDI2P) 4 Ground
5 MDI2- (MDI2N) 5 5V Dual
6 MDI1- (MDI1N) 6 USB1-
7 MDI3+ (MDI3P) 7 USB1+
8 MDI3- (MDI3N) 8 Ground
J7 : Secondary USBx2 + LAN Connector
PIN No. Signal Description PIN No. Signal Description (Top Con.)
1 MDI0+ (MDI0P) 1 5V Dual
2 MDI0- (MDI0N) 2 USB2-
3 MDI1+ (MDI1P) 3 USB2+
4 MDI2+ (MDI2P) 4 Ground
5 MDI2- (MDI2N) 5 5V Dual
6 MDI1- (MDI1N) 6 USB3-
7 MDI3+ (MDI3P) 7 USB3+
8 MDI3- (MDI3N) 8 Ground
J8 : Audio MIC/Line-in/Line-out Connector
PIN No. Signal Description PIN No. Signal Description
1 MIC with Reference Voltage 2 Analog Ground
3 Line-in Left Channel 4 Analog Ground
5 Line-in Right Channel 6 Analog Ground
7 Line-out Left Channel 8 Analog Ground
9 Line-out Right Channel 10 N/C
