Hardware Configuration
RUBY-9715VG2AR User’s Manual 2-6
Note:
The Reference Voltage on MIC signal offers 2.25V~2.75V with 5mA drive.
J9 : Audio CD-in Connector
PIN No. Signal Description
1 CD-in Left Channel
2 CD Ground
3 CD Ground
4 CD-in Right Channel
J10 : ATX8, 12V POWER Connector
PIN No. Signal Description PIN No. Signal Description
1 Ground 5 +12V
2 Ground 6 +12V
3 Ground 7 +12V
4 Ground 8 +12V
J11 : PCI Connector
PIN No. Signal Description PIN No. Signal Description
A01 TRST# (Pull-Low) B01 -12V
A02 12 V B02 4.7K Pull-Low
A03 PTMS (2.7K Pull-high 5V) B03 GND
A04 PTDI (2.7K Pull-high 5V) B04 N/C
A05 VCC B05 VCC
A06 PIRQ#F B06 VCC
A07 PIRQ#G B07 PIRQ#E
A08 VCC B08 PIRQ#A
A09 N/C B09 N/C
A10 VCC B10 N/C
A11 N/C B11 N/C
A12 GND B12 GND
A13 GND B13 GND
A14 N/C B14 NC
A15 PCIRST# B15 GND
A16 VCC B16 PCI Clock
A17 PGNT#5 B17 GND
A18 GND B18 PREQ#5
A19 PME# B19 VCC
A20 AD30 B20 AD31
A21 VCC3 B21 AD29
