Portwell RUBY-9715VG2AR - Page 17

Hardware Configuration
RUBY-9715VG2AR User’s Manual 2-7
A22 AD28 B22 GND
A23 AD26 B23 AD27
A24 GND B24 AD25
A25 AD24 B25 VCC3
A26 IDSEL (AD26) B26 C/BE#3
A27 VCC3 B27 AD23
A28 AD22 B28 GND
A29 AD20 B29 AD21
A30 GND B30 AD19
A31 AD18 B31 VCC3
A32 AD16 B32 AD17
A33 VCC3 B33 C/BE#2
A34 FRAME# B34 GND
A35 Ground B35 IRDY#
A36 TRDY# B36 VCC3
A37 GND B37 DEVSEL#
A38 STOP# B38 GND
A39 VCC3 B39 LOCK#
A40 N/C B40 PERR#
A41 N/C B41 VCC3
A42 GND B42 SERR#
A43 PAR B43 VCC3
A44 AD15 B44 C/BE#1
A45 VCC3 B45 AD14
A46 AD13 B46 Ground
A47 AD11 B47 AD12
A48 GND B48 AD10
A49 AD9 B49 GND
A50 KEY B50 KEY
A51 KEY B51 KEY
A52 C/BE#0 B52 AD8
A53 VCC3 B53 AD7
A54 AD6 B54 VCC3
A55 AD4 B55 AD5
A56 Ground B56 AD3
A57 AD2 B57 GND
A58 AD0 B58 AD1
A59 VCC B59 VCC
A60 4.7K Pull-High VCC B60 4.7K Pull-High VCC
A61 VCC B61 VCC
A62 VCC B62 VCC
